Mordheim Report #14 - The making of my new table


Hello again. This time I've come up with a doozy of an update. A new table for Mordheim! Below I try my best to break down every step how I did it.

This has been a long time coming. Drawing up inspiration and lessons from the first foldable table I made some 15 years ago. The actual spark for starting this project came when I was casually looking at some gaming mats (for Kill Team I guess), and realized they actually had deployment zones pre-measured on the table graphics themselves. That was a real tangible advantage I wanted to have in my new table.

From there gathered up the list I wanted to have in it:
- Pre-measured deployment zones. As said above.
- Strong wooden frame. My last one which is made of 2 inch foam is somehow slightly warped in weird directions.
- Make it more pretty. Old one was just two pieces of foam with some spare wood, hinges and other stuff slapped on to it.
- Take more advantage of the foam. Old table was pretty much all foam, but I never carved it in any way. I chose it just for its weight and durability.
- Make it more diverse. This time I used five-ish different textures on it instead of one.
- Try new techniques and hope for the best. Luckily pretty much everything worked out how I thought they would.


Here's the plan of making deployment zones on the table.
I also wanted to mark the center for whatever reason.
I'm used to work without doing any notes or graphs. This time though, I had plenty of spare time and a project I wanted to be proud of. So I made a little drawing to help me get everything out of my brain (not that much, durrr...), and on to the finished project.


The table frame, not made by me (thanks Antti!)

Stained and sealed. Again, not by me.
I commissioned a friend of mine to do the frame. Gave him the measurements, and chose the cheapest smooth wood available. He asked me if I want to to be stained also, and without giving it any thought I think I said "Sure, whatever", or something along those lines. Now thinking about it, I'm sure it was the right decision as I was told it would also resist any warping.


Start of the first zone.
The big circle has no other meaning than to break up the monotony.

Making the stone texture... with a stone.

2 cm (a little less than 1 inch) thick FinnFoam was chosen for the surface, and was cut in 4 feet by 2 feet pieces.
The frame and the surface is actually almost within one millimeter of the 4' x 4' common gaming table size, which is super awesome.

I wanted to work with textured wallpapers, but decided that it would be good variation to do something by hand. One of the four deployment zones would suffice for this.
I made the deployment zone tiles with ballpoint pen, textured them with anything that has a nice texture, and sealed with watered down PVA glue.

The other deployment zones were carved in. I used a soldering iron which has this carving-knife-tool attached to it. Cuts through like butter. Basic wall filler was used if a cut was too deep.



Masking is important.

Carved (or rather melted) the other deployment zones.

One of my miscast sewer grates got a new life here.

Put two textured wallpapers on top of each other and cut them.
Then swap the identical sized pieces and tape them.

All taped.

Use watered down acrylic paste and a piece of cloth for bendiness.
Here's the biggest part of the surface, the vinyl wall paper. For some reason I wanted to mark the center of the table (Mordheim doesn't really have a need for the exact center), and came up with this plaza type cobblestone design of sorts. The main reason for it though, was to break up the monotone texture of the dominant wall paper.

I took a wide slice of the other (green) wall paper, and taped it over the bottom one (red). Then I took a knife and cut through both at the same time to get identical pieces, then swapped out the pieces and taped them in place for gluing.
Flipped the taped wall paper design over, and glue it underside. I used watered down acrylic paste to adhere a piece of cloth to hold it tight.
Because the design marks the center of the table, it is in the spot the table folds, so no glue that dries hard, or warps, or does any other funky business would do.


Some additional texturing to break the monotone.
Here are pretty much all the detail I did to the table. Not much is needed when it is supposed to be covered in other terrain. I couldn't go buck wild with the foam melting either, because the surface needs to be pretty flat. Otherwise the buildings won't stay put.

Making marks!

All glued on and trimmed. Also a road has been added.

This is pretty much the final form of the surface. Wall papers have been trimmed and glued, the gutter and other "bald spots" have been cut through and made visible, and the road has been marked and started.

There was a slight problem with the design though. There is a 12 inch area in the middle of the table that can't be glued because the joint hinge is above the surface level, and would rip the paper off when folded. This left a bit of bulging in the wall paper (as seen above), which I didn't mind as much since it would - again - be covered with terrain. Miraculously though, this flaw corrected itself in the latter work steps. Read below.


The gutter.

Additional minor details.

Rubbing in some sand for additional texture.

The random sand texture to really break up the monotone of the wall paper. This was pretty much the last big work step to be done. I didn't know if it would work, and was super nervous how it would end up.

I made this watered down (to a light creme viscosity) PVA glue with aquarium sand, and some random color just to see where I've applied it. My vision was to rub it in the crevasses of the wall paper and hope the glue would hold it. The reality was that the sand wouldn't really go in the cracks and would be left all over the place. I compensated by adding more of the stuff.
In the end it worked out, really random patterns and the glue held good. A lot of the sand went to waste, and a lot of work (and sore fingers) was needed to rub the excess sand off. But now, my biggest worry was behind me.

The miracle that also happened, was that the watered down glue shrunk so much that it flattened all the bulges that formed when adhering the wall paper to the foam. I was glad indeed!


Lower part of this picture has been rubbed out of excess sand,
the top part is just glued.

A mud paste made out of acrylic paste, water, sand and wood dust.

A muddy road.

The last thing before painting is the road that marks the last deployment zone.
A paste was made from acrylic paste, water, that same sand, and wood dust. I settled on a stuff that was comparable thickness to a yoghurt. Applied it and ran the other end of a brush through it to simulate some wagon tracks.
Then after drying I picked off the bigger clumps to flatten it a bit.


Black spray paint.

A full coat of cheap-o brown acrylic was applied.
After this was gray spray paint.

A few different brown washes were applied at different spots.
Pictured above is the first and the heaviest one.

Without the light gray drybrush.

With the light gray drybrush.

Now was the time to get painting. First up were the gray parts.
The layers were as follows: Black spray, cocoa-brown acrylic (with some added acrylic paste to maybe protect the surface more), gray spray. Over the gray base I washed over with few different browns, leaving random spots and marks.
Once that was dry I went over with the same gray as the base, but with a bottled paint. Using long strokes and the brush almost horizontally, I carefully tried to only paint the raised parts of the vinyl wall paper.
The last thing to do was to drybrush the whole thing with one step lighter gray.


WIP brown parts. These have five-ish layers of different browns brushed and washed.
A few more to go still.
Fresh out of the masking removal.


Brown parts weren't given any thought at all. Just mixing different colors and seeing what shows up over the base color. Some washed, some brushed, and others drybrushed.
I think I ended up painting eight to ten brown layers overall, last one being really diluted smokey ink applied by my index finger.

After all the painting all there was to do was to varnish it, and remove the masking, and voilà!
Some minor repairs were necessary after the masking tape had ripped some of the paint off.

In the end I'd say I'm 90% pleased with my creation. There's a few thing that nag me a bit.
One being that the few reddish tiles I painted don't really show up, and kinda just look painted on. The other is that the sand particles might still - after so many precautions - get loose, and they might be bad with terrain that has really hard base. I think it would've been better to use wood dust instead of sand there.
Some paint may chip, and holes get poked on it, but that is just to be expected.

So here we have it. My new Mordheim table.

The very next day my table saw its first few games.




A cat warming her butt on a wireless router.

tiistai 16. toukokuuta 2017

What up bull?

He's starting to be ready to be painted.
There's still a handful of details to be glued on, but I wanted to seal off the gaps beforehand.

There's crazy amount of stuff you need to do when assembling Forge World miniatures:
Count the pieces, remove that huge gate mold, remove flash and seams (which were fortunately quite rare), remove miscasts, wash off the release agent, straightening any warped parts, fill bubbles, pin and glue together, putty gaps, file smooth if needed.

One last seam on his leg to be puttied. The biggest seam was going all around his neck.

Don't worry about that badly filed spot on his back. It's where the throne will be glued.


tiistai 4. huhtikuuta 2017

Test scheme for my Infernal Dwarfs

Hello again,

Today I bring you a batch of bad pictures of my Chaos Dwarf warrior I just finished. Red, black, metallic trimmings, and WHOLE LOT of washes. Only surface that has over two layers is the face. Everything else is just flat color and a layer of wash.
I really want to get these ready as soon as possible, hence the really simple plan of doing barely decent.
Also, my phone is the worst at contrast. As it turned out, I have to have a dark background for the miniature to show up at all. So I put that green thing behind him.




Anyway. Better pictures when I have few of them ready and on base.

keskiviikko 8. maaliskuuta 2017

Mordheim Report #13

Quick update on my first tall building. Going's been slow on this one since I need to think the folding again from the start. Hopefully I get it down with this and the next five similar building will come together more quickly.
What I've learned for now is that I should only do holes and bigger formwork before gluing walls to base with hinges. Floor layers are easier to match after that, and details are way easier to do when floors are in place, like that book shelf.
I'm thinking of doing this pretty much paint ready before going ham on the next five.

This first building is themed as a small library, with tiny alchemy table at the top floor (which is not done yet), finished with some sun iconography. The bottom floor is not accessible.
I'm yet to decide all the themes for the rest. Only ones I have in mind besides the aforementioned is a butcher, and fish market/fishing supplier store. Maybe the rest are just going to be apartments and housing...






perjantai 27. tammikuuta 2017

Lets start the new year

I've been taking holiday, flu, and general disinterest breaks from building minis, but now my fever has gone up again. A miniature fever that is.

Warhammer 40k is a game that I started 20'ish years ago with a friends, and we all fell off it quite quickly (my friends fell from miniatures as a whole). Just before new year one of them informed me that he's taken up on Kill Team, a 40k game that has just a handful of troops. Pretty much like Mordheim but with 40k stuff.
There is few variations of the game, the official GW version, and the unofficial Heralds of Ruin. He decided, after looking up reviews, that HoR was the way to go.
So here we go, back to the world of grim darkness of the future where there is only war.


In my unending quest of how to save space with gaming terrain, I've had some ideas for sci-fi terrain but no reason to build any. Now I have.
The original idea was to make hexagonal (the most sci-fi shape there is!) buildings that could nest inside each other. I deviated from this plan by having octagonals, because they are easier to do.


I left the evidence in the picture of my Kill Team Orks waiting to be assembled.



There we have some WIP pictures to show off my friends what I have cooking.
The biggest octagon is a landing pad of sorts, and if you don't like the height, you can flip it over to get a big missile silo thingy. The pad has a diameter of 12", so you can place it in the middle of the board in some missions to also have it act as a deployment zone.
The cardboard box is the next big building (most likely a rusted out silo) that can be inserted between landing pads struts.

All of these are of course heavily WIP, and I intend to keep these relatively simple compared to my Mordheim stuff. No interiors and simple forms (for obvious reasons).
Only planned things for the pad is additional structural cross sections to struts, maybe some rivets, and finish it off with some sand and gravel spots.

keskiviikko 23. marraskuuta 2016

Mordheim Report #12

These things are now ready. 6 ladders and fences, and 2 walkways.

They had their debut yesterday, when I had my first game of our campaign. Unfortunately I lost, and two on my members got dead!
After scavenging for the Wyrdstone I managed to get just enough money to replace them, and additionally had three bows to spare around. So all in all, I ended on the plus side.


Not much to say about these things. Ladders and walkways are done mostly with wooden sticks.

Fences are done by texture roller over some polymer clay. The first quarter of a single fence was actually just a test piece when I got the rollers. I ended up making six of them because the test piece looked good, and I just had bought some big ice cream sticks which ended up as the bases.

Barrels and wheels are of course those I've made with toy dough.

maanantai 31. lokakuuta 2016

Mordheim Report #11

My Possessed warband is getting there. Only two Possessed, one Gor, and a few henchmen to go. This time I got Gor, Magister and a Mutant ready, who are posing in the first row in pic below.


Here's the box I have for them. Custom slots for the metallics, and one size slots for plastics.
I've not yet done all the henchmen since I really don't know how many or what kind I need or want besides the three Gors.
